op id:44ceb5d8-b040-4722-b189-a6fb8172517d
Triggers one of the out ports (value index switch case)

summary (oneliner)


youtube id


related ops


Execute (Function)

Switch Value (integer Number)


Next Trigger (Function)

Switched Value (Number)

Trigger 0 (Function)

Trigger 1 (Function)

Trigger 2 (Function)

Trigger 3 (Function)

Trigger 4 (Function)

Trigger 5 (Function)

Trigger 6 (Function)

Trigger 7 (Function)

Trigger 8 (Function)

Trigger 9 (Function)

Default Trigger (Function)

Switch Trigger Example:

SwitchTrigger triggers one of the output triggers based on the value of the input port.
By Using the Incrementor op we cycle between a number in the range [0..3], which then either draws a sphere, cube, torus or cylinder.

Click anywhere in the patch area and press "f" to turn on the flow-mode (you can also press "cmd + p" and enter "flow"). Now click in the renderer window and click several times. You will see how the flow of the yellow trigger cables changes.

video tutorial:
